Electroheat ECO-V inverter side venting pool heat pump
The new Electroheat ECO-V inverter technology side venting pool heat pump range in 7, 12, 15, 20 & 27kW capacities feature a sophisticated and advanced outer shell design in Waterco’s signature pewter colour and have heating and cooling capabilities.
-
Energy efficient inverter technology
Electroheat ECO-V inverter pool heat pumps utilise a variable speed compressor to regulate the pool water temperature automatically and independently.
• inverter technology uses a variable speed compressor motor similar to a cars engine
• it slows down and speeds up as needed to hold a selected desired temperature or speed
• the desired temperature will be reached more quickly and maintained more efficiently
• inverter technology provides a more precise water temperature without the fluctuations and power wastage of fixed speed systems
• inverter technology is significantly more energy efficient with energy savings of between 15 - 30% over fixed speed systems
• the speed control of the compressor and fan motor also means quieter operation
-
Automatic evaporator de-icing
Electroheat ECO-V inverter pool heat pumps feature automatic de-icing for situations where frost or ice may develop on the evaporator as part of normal operation. Common in cooler climates or winter months, when a build-up of ice is detected the heat pump shifts temporarily into cooling mode to reverse the flow of refrigerant through the evaporator coils. Hot refrigerant moves through the outside coils, melting ice and defrosting the system. When the defrost cycle is complete, the unit shifts back to heating mode.
-
- Heating pools in winter months May – August should be achieved using maximum day time operation of eight hours. A pool cover is necessary to achieve desired temperature in winter.
The Electroheat ECO-V inverter side venting range of pool heat pumps allow the pool owner to heat their pool in cooler climates even when the ambient air temperature is close to 0°C. The ECO-V range are ideal solution to heat swimming pools, plunge pools, swim spas and spas to extend the swim season or for year round enjoyment. They are available in 7, 12, 15, 20 & 27kW heating and cooling models.
About Waterco’s Inverter Technology Pool Heat Pumps
- Variable speed compressor automatically and independently regulates pool water temperature
- Similar to a car’s engine, it slows down and speeds up as required to hold a set temperature
- Desired temperatures are reached more quickly and maintained more efficiently
- Eliminates temperature fluctuations and power wastage common with fixed speed systems
- Estimated energy savings of up to 20 per cent compared with fixed speed systems
- Quieter operation due to the compressor and fan motor speed control
Key features of the Electroheat ECO-V 7, 12, 15, 20 & 27kW Inverter pool heat pumps:
- Inverter technology improves energy efficiency
- Side venting design allows for greater installation options
- Digital controller with diagnostics
- Heating and cooling operating modes to select from
- Supplied drainage spigots allow piping to drain away the condensate
- Refrigerant pressure gauge indicates the level of refrigerant charge held within the unit
- Hydrophilic blue fin coated evaporator protects unit from erosion in humid and coastal environments
- Automatic hot gas evaporator de-icing removes ice build up
- R32 refrigerant for zero ozone depletion
The Electroheat ECO-V inverter side venting range of pool heat pumps allow the pool owner to heat their pool in cooler climates even when the ambient air temperature is close to 0°C. The ECO-V range are ideal solution to heat swimming pools, plunge pools, swim spas and spas to extend the swim season or for year round enjoyment. They are available in 7, 12, 15, 20 & 27kW heating and cooling models.
About Waterco’s Inverter Technology Pool Heat Pumps
- Variable speed compressor automatically and independently regulates pool water temperature
- Similar to a car’s engine, it slows down and speeds up as required to hold a set temperature
- Desired temperatures are reached more quickly and maintained more efficiently
- Eliminates temperature fluctuations and power wastage common with fixed speed systems
- Estimated energy savings of up to 20 per cent compared with fixed speed systems
- Quieter operation due to the compressor and fan motor speed control
Key features of the Electroheat ECO-V 7, 12, 15, 20 & 27kW Inverter pool heat pumps:
- Inverter technology improves energy efficiency
- Side venting design allows for greater installation options
- Digital controller with diagnostics
- Heating and cooling operating modes to select from
- Supplied drainage spigots allow piping to drain away the condensate
- Refrigerant pressure gauge indicates the level of refrigerant charge held within the unit
- Hydrophilic blue fin coated evaporator protects unit from erosion in humid and coastal environments
- Automatic hot gas evaporator de-icing removes ice build up
- R32 refrigerant for zero ozone depletion
